4.8級十字槽沉頭螺釘 NF E 25-119-1 - 1994

選擇規格尺寸點擊↓

M1.6

M2.5

M3.5

M10

尺寸單位: mm

法國NF E25-119-1 - 1994 NF25-119-1 25-119- 4.8級十字槽沉頭螺釘

掃一掃分享

單重計算公差公制螺紋極限尺寸米/英制螺紋對照螺紋直徑與受力截面積最小破壞扭矩牌号等級毛坯直徑

千件重及價格計算千件重 : kg x 元/kg = 元/千件

默認密度 g/cm³

螺紋規格
d

M1.6

M2.5

M3.5

M10

P	螺距
b	最小值
d_k	最大值
d_k	最小值
k	最大值
槽号

0.35	0.4	0.45	0.5	0.6	0.7	0.8	1	1.25	1.5
25	25	25	25	38	38	38	38	38	38
3.0	3.8	4.7	5.5	7.30	8.40	9.30	11.30	15.80	18.30
2.7	3.5	4.4	5.2	6.94	8.04	8.94	10.87	15.37	17.78
1	1.2	1.5	1.65	2.35	2.7	2.7	3.3	4.65	5
0	0	1	1	2	2	2	3	4	4

千件鋼制重≈kg

替代列表

暫無

等效标準

國标 GB	國際 ISO	德标 DIN	意大利 UNI	法國 NF
GB /T 819.1	ISO 7046-1	DIN EN ISO 7046-1	UNI 7688	NF E 25-119-1

以上有部分标準可能為近似等效，如有異議以标準原件為準

引用參考

GB /T 1172 - 1999

黑色金屬硬度及強度換算值

GB /T 5267.1 - 2002

鍍鋅、鍍鎳、鍍镉、複合鍍等層鍍層鹽霧腐蝕的防護性能

GB /T 193 - 2003

普通螺紋（一般用途米制螺紋）- 直徑與螺距系列 (ISO 261: 1998, MOD)

GB /T 3106 - 2016

緊固件 - 螺栓、螺釘和螺柱 - 公稱長度和螺紋長度 (ISO 888:2012, MOD)

GB /T 3 - 1997

普通螺紋收尾、肩距、退刀槽和倒角 (ISO 3508:1976 / ISO 4755:1983)

GB /T 5779.1 - 2000

緊固件表面缺陷 - 螺栓、螺釘和螺柱 - 一般要求

GB /T 5779.3 - 2000

緊固件表面缺陷 - 螺栓、螺釘和螺柱 - 特殊要求

注：技術數據僅供參考，請以官方原件為準！
